SG7-5C nobengr Metal ZJM Coupling Flexible Disc Couplings
Material: Aluminum Alloy
Finish: Anodizing Silver
Features:
1. Plate spring coupling
2. Excellent response and high torque capacity
3. Zero backlash
4. Identical clockwise and anticlockwise rotational characteristics
5. Stainless steel plate spring absorb angular misalignment and shaft end-play
Application: Use for servo motor and stepper motor
Remark:
1. The moment of inertia and the quality is calculated according to the maximum shaft hole
2. Bore dimensions can be customized
