SG7-GIICL nobengr GIICL Type Gear Coupling Drum Shape Toothed Rigid Shaft Coupling
Material: 40Cr/42CrMo
Features:
1. Small teeth pitch and allows small radial relative displacement
2. Compact structure and low moment of inertia
3. Can be rotated in two directions
4. The torque transmitted can be in the range of 400 through 5000000 N.m
Application: Suitable for connecting two horizontal co-axial shaft
Remark:
1. It is recommended to use integrated structure of sealing end cover with internal gearing
2. Bore dimensions can be customized
